drylin® E stepper motor with connector, NEMA 17

  • Installation Size: NEMA 17 / flange dimension 42 mm
  • Protection class: Motor housing IP65 (shaft sealing IP52)
  • Holding torque: 0.50 Nm
  • Nominal current: 1.80 A
  • Motor connection: M12 metric connector
Product description
NEMA17: Small, but lots of power

This little motor has impressive torque and high RPMs. Reliable operation with quick movements of low loads.

Stepper motors from igus® are a good supplement to drylin® linear axes. They are characterised by their cost-effectiveness, their precision and easy control. They work reliably under the most varied environmental conditions (depending on the selected class of protection IP). The igus® stepper motors can be connected to the most common motor controls using standardised electrical connection.

The connector interface provides a high IP65 protection level (IP: International Protection). The higher the IP rating, the better the motor is protected from the ingress of dirt and water.
