iglidur® A350, sleeve bearing with flange, mm

  • Very good coefficient of friction
  • Low humidity absorption
  • Good wear resistance under water
  • High media resistance
  • Resistant to high loads (>60 N/mm²)
  • FDA-compliant
  • EU 10/2011-compliant
Product description
iglidur® A350 | The endurance runner at higher temperatures in the food sector
iglidur® A350 knife edge rollers are made for practically all loads in food and packaging machinery. Even high loads are no problem and the rollers work reliably without additional lubrication.

Typical application areas

Food industry
Beverage industry
Medical technology

You can find further applications here:
Industry solutions


When to use it?
  • When lubrication-free deflection of conveyor belts is required
  • When FDA-compliance is required
  • When precise guiding is required
  • If wear-resistance and FDA conformance are necessary at high loads
  • If the bearing is used in an acid environment
  • When a cost-effective and easy-to-install solution is required
When not to use it?
  • When high belt speeds are
    necessary
  • When temperatures are continuously higher than +180 °C
  • When high forces are applied on the belts
  • When a static knife edge
    is required
Use our filter options to find the suitable product

Tolerances and measurement system
The installation dimensions and tolerances of the iglidur® knife edge rollers are dependent on the material and wall thicknesses. For each material, the moisture absorption and the thermal expansion are decisive factors.
Testing methods


Certifikater og standarder
RoHS compliant
According to 2011/65/EU (RoHS 2)
